Page 29 - Manual FA01383-EN - 04/2021 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
New user
Register up to a maximum of 250 users and assign a function to each one.
The operation can be carried out by using a transmitter or another control device. The boards that manage the control devices (AF - R700 - R800) must
be inserted into the connectors.
U1 New user 1 = Step-by-step
2 = Sequential
3 = Open
4 = Partial opening
When the barrier is in [Paired] mode, the [Partial opening] command opens the Master
barrier.
Choose the function to be assigned to the user.
Press ENTER to confirm.
You will be asked to enter your user code.
Send the code from the control device.
Repeat the procedure to add other users.
Remove user
Remove one of the registered users.
U2 Remove user OFF (Default)
ON
Use the arrows to choose the number associated with the user you want to remove.
No. 1 > 250
Alternatively, the control device associated with the user you want to remove can be
activated.
Press ENTER to confirm.
Remove all
Remove all registered users.
U3 Remove all OFF (Default)
ON
Radio decoding
Choose the type of radio coding for the transmitters enabled to control the operator.
If you choose the type of radio coding for the transmitters [Rolling code] or [TW key block], any transmitters with a different type of radio coding saved
previously will be deleted.
U4 Radio decoding 1 = All (Default)
2 = Rolling code
3 = TW key block
Self-Learning Rolling
Save a new transmitter by activating acquisition from a remote control that has already been saved (see the remote control manual).
U8 Self-Learning Rolling OFF (Default)
ON
Boom length
Set the boom length.
A1 Boom length 3 = 3 m boom
4 = 4 m boom
6 = 6 m boom
8 = 8 m boom
