4.0 03/2009 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
4.1 Gate Operator
This product is engineered and manufactured by CAME cancelli automatici s.p.a. and complies with current safety regulations.
Guaranteed 24 months if not tampered with.
The gearmotor is formed of a motor in an armoured die-cast aluminium casing and a die-cast aluminium reduction gear casing which
contains a worm screw – helical gear – lead screw system.
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
2 Intended use and applications
The KRONO gearmotor is specifi cally engineered to automate residential and condominium swing gates.
The use of this product for purposes other than those described above and installation executed in a manner other than as
instructed in this technical manual are prohibited.
3 Reference Standards
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL OR QUALIFIED INSTALLERS”
2.2 Application
The company CAME cancelli automatici is ISO 9001:2000 quality certified; it has also obtained the ISO 14001 environmental
safeguarding certification. CAME engineers and manufactures all of its products in Italy.
This product complies with the following legislation: see declaration of compliance.
There are various models of the gearmotor available:
001KR300D - Right hand irreversible gearmotor for leaves up to 3m.
001KR300S - Left hand irreversible gearmotor for leaves up to 3m.
001KR310D - Right hand irreversible gearmotor with microswitches incorporated for stopping the leaf, for leaves up to 3m.
001KR310S - Left hand irreversible gearmotor with microswitches incorporated for stopping the leaf, for leaves up to 3m.
001KR510D - Right hand irreversible gearmotor with microswitches incorporated for stopping the leaf, for leaves up to 5m.
001KR510S - Left hand irreversible gearmotor with microswitches incorporated for stopping the leaf, for leaves up to 5m.
Accessories:
001KR001 - Yale lock with DIN key.
Type KR 510
Length of gate leaf (m) 22.53 4 5
Weight of gate leaf (kg) 1000 800 600 500 400
Type KR 300 - KR 310
Length of gate leaf (m) 22.53
Weight of gate leaf (kg) 800 600 400
