CAME PLACO-VC - Wall Mounting; Recessed Installation

4
43,5
45
7,5
57
70
106
A
B
64,5
70
145
A
B
500 mm
1080 mm
77°
94°
800 mm
500 mm
163,5 mm
43,5 mm
H= 165 cm
(HAUTEUR
CONSEILLÉ)
500 mm
1080 mm
77°
94°
800 mm
500 mm
163,5 mm
43,5 mm
M2M1
+–
EN
1
Technical features
Power supply: 230VAC50-60Hz
Current absorbed
I
max
200mA
AC
AC
Power dissipated: 10Wmax
Rated power supply: 18VDC1A-0.5A1’/3’
Dimensions: 4DIN
Storage temperature: -25°C+70°C
Operating temperature: 0°C+35°C
IP degree: IP30
Wall mounting
WiththeAllenwrench,unscrewtheblockingscrewsandremovetheplate(gure1).Fixthegivenplugsand
screwthe entrypanel(gure2-) atthe desiredheightconsideringthepositionofthe lensof thecamera
(gure3).
Runthesheathwiththesystemconductorsasshowningure2.Extracttheplasticterminalcoverandwire
theconnections(gure4).
Oncealltheconnectionshavebeenmade,re-inserttheterminalcovers.Installthefrontplate(gure1).
Recessed installation
Installtherecessedboxatthedesiredheightconsideringthepositionofthelensofthecamera(gure3),but
inadvance,runthehosewiththesystemconductorsthroughoneofthebreakingpoints(gure5pointA).
Duringinstallationoftherecessedboxitispossibletoavoidanydeformationbyusingtheprovidedspacer
(gure5pointB).
WiththeAllenwrench,unscrewtheblockingscrewsandremovetheentrypanelplate(gure1).
Introducethecableconnectionsinthespecialhole(gure2)andxtheentrypanelontheframeasshownin
gure6;extracttheplasticterminalcoverandwiretheconnections(gure4).Oncealltheconnectionshave
beenmade,re-inserttheterminalcovers.
Installthefrontplate(gure1).
1
Installation
The power supply must ALWAYS be installed vertically.
TheunitcanbeinstalledonaDINguide(EN50022)inaspecialelectricalpanel.
Fortheoveralldimensions,seeg.1.
Provide sufficient ventilation if the power supply is installed in a container.
Terminal boards
M1
~
230Vmains
~
M2
–
+
18VDCpowersupply(*)
(*)Theunitisprotectedagainstoverloadsand
shortcircuits.
H=165cm
(RECOMMENDED
HEIGHT)
1
2
5
6
3
4
VAS/101CM
PLACOVC
