GENERAL INSTRUCTIONS FOR INSTALLING
⚠
Only skilled, qualified staff must install this product in full compliance with the law in force.
⚠
If the door is fitted with a pedestrian door, you must also fit a safety switch at the entrance, to stop the
operator from working when the pedestrian door is open.
Preliminary checks
⚠
Before beginning the installation, do the following:
• make sure you have set up a suitable dual pole cut off device along the power supply that is compliant with the
installation rules. It should completely cut off the power supply according to category III surcharge conditions
(that is, with minimum contact openings of 3 mm);
• Set up suitable tubes and conduits for the electric cables to pass through, making sure they are protected
from any mechanical damage;
• make sure that any connections inside the container (ones that ensure continuity to the protection circuit)
are fitted with additional insulation with respect to those of other electrical parts inside;
• make sure that the door is properly balanced. When stopped at any point, it must maintain its position.
Slide guides
001V06001
Chain guide L = 3.02 m.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional* doors up to 2.20 m in height.
001V06002 Chain guide L = 3.52 m.
- Counter-balanced overhead doors up to 2.75 m in height.
- Sectional* doors up to 2.70 m in height.
001V06003 Chain guide L = 4.02 m.
- Spring-balanced overhead doors up to 3.25 m in height.
- Sectional* doors up to 3.20 m in height.
001V06005 Belt guide L = 3.02 m.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional* doors up to 2.20 m in height.
001001V06006 Belt guide L = 3.52 m.
- Counter-balanced overhead doors up to 2.75 m in height.
- Sectional* doors up to 2.70 m in height.
001V06007
Belt guide L = 4.02 m.
- Spring-balanced overhead doors up to 3.25 m in height
- Sectional* doors up to 3.20 m in height.
