CAME Wi-Fi PLX V User Manual

Page 12 - Manual - FA01792-EN - 10/2022 © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Example set-up without VA/01
XDV/304
VAS/101
Lb
La
PLX V Wi-FiPLX V Wi-Fi
Lc
PLX V Wi-Fi PLX V Wi-Fi
1
2
KIT
1
2
KIT
1
2
KIT
1
2
KIT
1
3
42
VAS/101
Lb
PLX V Wi-Fi
1
2
Lc
SLAVE SLAVE
KIT
1
2
ON
1
2
ON
1
Section Max. section length (m) Max. section length (m)
La + Lb 100 with VCM/1D cable 20 with UTP CAT5 cable
Lc 25 with 2x1 mm2 cable 60 with 2x2.5 mm2 cable
VCM/1D UTP CAT5
Wi-Fi PLX V (MASTER) 11
SLAVE RECEIVERS 22
The SLAVE receiver is a generic low-consumption receiver. The closing resistor must be activated on the last one in the line.
