Electrical connections
Antenna connection
EN
(N.C.) contact for «re-open during closing phase»
10-E1
2-7
2-C3
1-2
10-11
10-5
2-C1
L-N
230V (a.c.) Power, 50/60Hz frequency
Terminals for powering the following accessories:
- 24V A.C. normally;
- 24V D.C. when the emergency batteries are
working;
Maximum allowed power: 37W
Stop button (N.C. contact)
Key selector and/or command button (N.O. contact)
Movement flashing light (Contact range: 24V
– 25W max)
«partial stop» (N.C.) contact
Open-gate status light (contact range: 24V – 3W max)
2-3P
Key selector and/or partial opening button (N.O.
contact)
2-C7
«Open while closing»(N.C.) contact
(Sensitive edges).
2-C8
«close while opening» (N.C.)contact
(Sensitive edges).
Connection limit switch opens (N.C.)
Connection limit switch closes (N.C.)
F-FA
F-FC
+
E
-
M-N
24V (d.c.) motor with Encoder
- White
- Brown Encoder
- Green
