WARNING
(NACE SERVICE)
HAZARDOUS GAS AND PRESSURE HAZARD IN NACE QUALIFIED
SERVICE. USE ONLY NACE QUALIFIED REPLACEMENT PART
S
FOR HOUSINGS, BOLTS, AND BUA. FOR NACE BOLT PART
NUMBERS, REFER TO TABLES 4-3 & 4-4
.
ANY DEVIATION FROM USE OF QUALIFIED NACE PARTS IN
NACE SERVICE WILL VOID THE INSTRUMENT/DPU NACE
RATING(s)
.
Table 5-1. 199 Parts List
ITEM DESCRIPTION PART NO.
PER
UNI
T
1 BELLOWS UNIT ASSEMBLY (BUA) (SPECIFY) 1
*2 POST, CALIBRATION SPRING RETAINER
(FOR 3-3/4" BELLOWS)
0199-0019C 4
3 ROD, SPRING PUSH 0199-0049C 1
*4 SCREW, RETAINER, 6-32 x 5/16" 0111-0049J 8
*5 SPRING ASSEMBLY, CALIBRATION TENSION
(FOR 2-1/8" BELLOWS)
(SPECIFY) 1
6 NUT, LOCK - SPRING ADJUST 0199-0144C 1
7 PLUG, PIPE, 1/4" NPT, STEEL 0199-0191C 2
8 PLUG, PIPE, 1/2" NPT, STEEL 0199-0192C 2
9 BOLT, HOUSING (STANDARD UNITS):**
STAINLESS STEEL, 1000 PSI UNITS
STEEL, 2500/3000/4500 PSI UNITS
STUD, ALLOY STEEL, 1/2-20 X 7 FOR 6000
PSI UNITS (NOT SHOWN
)
BOLT FOR 6000 PSI UNITS (NOT SHOWN)
0199-1345C
0199-0085C
0199-1001C
0199-1346C
A/R
*10 SCREW, PIPE MOUNT ADAPTER, 3/8-16 X 3/4" 0210-0012J 1
11 SCREW, SCH CAP, STEEL, 3/8-16 X 1-1/2" LG. 0220-1102J 2
*12 SCREW, 3/8-16 X 5/8", STEEL (FOR ITEM 13) 0310-0013J 3
13 ADAPTER, PIPE MOUNTING 0199-0988C 1
*14 NUT, SPRING RETAINER, HEX, 6-32,
SM PATTERN, SST (FOR 3-3/4" BELLOWS)
0500-0028J 8
*15 ASSEMBLY, RANGE SPRING
(FOR 3-3/4" BELLOWS)
(SPECIFY)
1
16 SPACER, INDICATOR BRACKET 0199-0006C 2
17 SCREW, INDICATOR BRACKET
(SOC. FLAT, 3/8-16 X7/8", ST)
0240-0003J
1
18 BRACKET (SPECIFY) 1
19 SCREW, INDICATOR BRACKET, HEX, WASHER
HD., 3/8 X 1-1/
8
0002-1009T
2
20 SCREW, RECORDER BRACKET, HEX, WASHER
HD., 3/8-16 X 1/2
0002-0034T
1
