Table 5-1. 199 Parts List (Continued)
ITEM DESCRIPTION PART NO.
PER
UNI
T
*21 O-RING, 2-127, NITRILE N3 ** 0001-1178R 1
*22 GASKET, TORQUE TUBE 0199-0209C 1
23 NOT USED
24 SCREW, RECORDER BRACKET, HEX, WASHER
HD., 3/8-16 X 5/
8
0002-0033T
2
*25 GASKET, PRESSURE HOUSING: **
1000 PSI ALUMINUM UNITS
2500/3000/4500 PSI STEEL UNITS
1000/3000/6000 PSI SST & MONEL UNITS
0199-0027C
0199-0027C
0199-0184C
2
26 HOUSING, PRESSURE (SPECIFY) 2
27 WASHER, LOCK, 3/8"
(USED WITH ITEMS 10 AND 11)
0275-0049C
1
28 NOT USED
29 NUT, 1/2-20, 6000/3000 PSI MONEL UNITS
(USED WITH ITEM 9)
0199-1002C
A/R
*30 PLUG, DAMPENER VALVE (NOT SHOWN)
BD HD., 1/4-28 X 1/4, SST
0199-0036C
1
31 NOT USED
*32 WRENCH, RANGE SPRING ADJUSTMENT 0199-0142C 1
33 KEYS, SET OF HEX (NOT SHOWN) 0016-0013T 1
NOTES: * INDICATES RECOMMENDED SPARE PART; A/R INDICATES AS
REQUIRED; WHEN ORDERING PARTS, SPECIFY INSTRUMENT SERIAL NUMBER
.
** FOR NACE SPECIFIC PART NUMBERS, REFER TO TABLES 4-3 AND 4-4.
