CAMPAGNOLO EPS - EPS Front Derailleur Maintenance; EPS Rear Derailleur Maintenance

COMPONENTS
MAINTENANCE - Rev. 01/ 06-20194
2 - EPS FRONT DERAILLEUR
PROCEDURE
MILEAGE IN KM
(MAX)
check screws are tightened to the cor-
rect torque
Torque
wrench
PROCEDURE
MILEAGE IN KM
(MAX)
check screws are tightened to the cor-
rect torque
Torque
wrench
• Check that the front derailleur is oriented correctly:
- the derailleur cage must be 1.5÷3 mm from the largest
chainring.
- the external side of the derailleur cage must be parallel to
the largest chainring.
Periodically clean and lubricate the pivots of the front and
rear derailleurs with non-aggressive oil for thermoplastic
components.
• Make sure you do not damage the component because the
three pivots are press fitted using knurls (one on the short
pivots and two on the long pivot).
• The derailleur cage can be replaced (as with mechanical
systems) by contacting a Campagnolo Service Centre.
1.5 – 3 mm
3 - EPS REAR DERAILLEUR
• Periodically lubricate all the joints with non-aggressive oil for
thermoplastic components.
• If the wheels do not rotate smoothly, thoroughly clean them
or replace if necessary.
• To remove the wheels, unfasten the screws using the 3 mm
Allen wrench.
Caution!
The wheel marked “UPPER” must be fitted on the topside
and the wheel marked “LOWER” on the underside.
Caution!
When replacing the wheels, comply with the following:
TIGHTENING TORQUE: 2.7 Nm (24 in.lbs)
