to "Callback". The remaining parameters in the instruction are ignored. The resulting instruction
will look similar to:
SendVariables (SendResult, COMRS232, 0, 4094, 0000, 0, "Public", "Callback",
Scratch, 1)
After LoggerNet receives the variable "Callback" it will begin collecting data from the data logger
and store it to a file based on the data collection settings in the Setup window. See the CRBasic
help for more information.
6.4.4.3 Set up hardware
1. Connect the Cellular antenna.
2. Connect your data logger to the CELL200-series module RS-232 or CS I/O port. See Wiring
and connections (p. 25).
3. If not connecting through CS I/O, provide power to the CELL200 series.
6.4.4.4 Set up LoggerNet
The LoggerNet Network Map is configured from the LoggerNet Setup screen.
NOTE:
Setup has two options, EZ (simplified) and Standard. Click on the View menu at the top of
the Setup screen, and select Standard view.
From the LoggerNet toolbar, click Main > Setup and configure the Network Map as described in
the following steps:
1. Select Add Root > PakBusTcpServer.
2. Add a data logger to the PakBusTcpServer.
CELL200-Series 4G LTE Cellular Module 47
