C.1 Using cell modem terminal functionality
NOTE:
This functionality is available in all CRBasic data loggers with a CS I/O port.
CELL200 series settings configuration and status retrieval using terminal functionality (p. 65)
shows how to set up an attached CELL200-series module using the terminal functionality in the
module. It also illustrates how to use the same functionality to retrieve status information from
the CELL200 series and put the module into low power mode. This program can be
downloaded from https://s.campbellsci.eu/documents/eu/miscellaneous/CELL2XX-Settings.dld.
To use the terminal functionality of the module, you must enable the terminal port. To do this:
1. Connect a USB cable between your module and computer.
2. Connect the Cellular antenna.
3. Connect the Diversity antenna, if used. (Not required. See Antenna connections (p. 29).)
4. Open a web browser and go to: www.cell.linktodevice.eu/.
TIP:
If your computer does not respond to the DNS server correctly, browse to 192.168.86.1.
5. On the Settings | Advanced tab, set the Terminal Port CS I/O SDC Address. (It must be set
to a different address than the one used for the CS I/O Port SDC Address.)
6. Click Apply Changes.
CRBasic Example 3: CELL200 series settings configuration and status retrieval using terminal
functionality
Public modem_apn As String * 50 'Current Access Point Name
Public modem_battery_voltage 'Modem's current battery voltage
Units modem_battery_voltage = V
Public modem_current_day_usage As Long 'Today data usage statistics
Units modem_current_day_usage = kB
Public modem_current_month_usage As Long 'Current month's data usage
Units modem_current_month_usage = kB
Publicc modem_diversity As String 'Current setting for the Diversity Antenna
Public modem_ecio 'Current ECIO value (3G signal quality)
Public modem_ipprotocol As String 'Current setting for IP Protocol (IPv4,
'IPv6, or IPv4/IPv6)
Public modem_mode As String 'Current modem mode (PPP or Serial Server)
Public modem_previous_day_usage As Long 'Previous day's data usage
Units modem_previous_day_usage = kB
CELL200-Series 4G LTE Cellular Module 65
