Campbell CELL205 User Manual

6.3.1 Module communications connections 25
6.3.2 Module power connections 28
6.3.3 Antenna connections 29
6.4 CELL200 series and data logger configuration 30
6.4.1 Integrated mode option 30
6.4.2 Non-integrated mode option 30
6.4.3 Serial server mode option 36
6.4.4 Serial client mode option 43
6.4.5 Serial server/client mode option 49
6.1 Base station requirements
A computer running Campbell Scientific LoggerNet software with access to the Internet is
needed.
6.2 Data logger site equipment
l CELL200-series module with power cable (included with module)
l Data logger — CR1000X series, CR300 series, CR6 series, CR1000, CR3000, CR800 series,
CR5000, and GRANITE 6/9/10
l Module Interface, see Module communications connections (p. 25)
l Environmental Enclosure — ENC10/12, ENC12/14, or ENC16/18
If connecting to CS I/O port:
SC12 cable (preferred for CR1000X series, CR300 series, CR6 series, CR1000, CR3000,
CR800 series, CR5000, and GRANITE 6/9/10 data loggers ) — connects the module to
current data logger with a CS I/O port. See CS I/O connection (p. 27)
SC105 Interface — connects the module to any data logger with a CS I/O port. It must
be configured using Device Configuration Utility. Settings should be:
l CS I/O Mode: Modem Enable
l CS I/O ME Baud Rate: 9600
l RS-232 Mode: Modem (default)
l Baud Rate:
l 115.2K for CR1000X series, CR300 series, CR6 series, CR1000, CR3000, CR800
series, CR5000, and GRANITE 6/9/10 data loggers
CELL200-Series 4G LTE Cellular Module 23
