71
Ref
#
Name of
Part
Part ID
DynaFlame Model
ALL
500 750
1100 1200 1500 1750 2000 2500 3000 3500 4000 4500 5000 4504 5004 6004
15
Outer Jacket
Right Panel
14-6012
-05A -07A -11A -11A
14-5223
-15A -17A -20A -25A -30A -35A -40A
-
45A
-50A
14-5323
-45 -50 -60
16
Outer Jacket
Rear Panel
14-6021
-05A -07A -11A -11A
14-5224
-15A -17A -20A -25A -30A -35A -40A
-
45A
-50A
14-5324
-45 -50 -60
17
Top
Transition
Inner to
Outer
Jackets
14-6025A X X X X
14-5225A X X X X X X X X X
14-5325 X X X
18
Outer Jacket
Top Cover
Assembly
14-6030A X X X X
14-5228A X X X X X
14-5228A-50 X X X X
14-5329-45-50 X X
14-5329-60 X
19 Junction Box 14-5240A X
20 Display Bezel 90-10004 X
21
Vent
Transition
Disk
14-5279 X
22 Rear Filter
109265-10 X X X X X
109265-12 X X X X
1092665-14 X X X X X X X
23
Back Cover
Plate
(Condensing)
14-6022A X X X X X X X X X
14-5323A X X X X X X X
24
Back Cover Plate
(Non-
Condensing)
14-6023A X X X X X X X X X
14-6023A-50 X X X X X X X
