56 Differential Gas Switch C6097B X
57 Water High Limit
L6008A1242 (Auto
Reset)
X
L4008E1313 (Manual
Reset)
X
58 Water Pressure Switch HB26A218L X
59
Graphite-Backed White
Ceramic Gasket(1)
33-5244 X X X X X X X X X
33-5241 X X X X
33-5243 X
33-5245 X X X X
60 Red Silicone Gasket (1)
33-5221 X X X X X X X
33-5218 X X
33-5224 X X X X
33-5227 X
33-5230 X X X X
61 Graphite Gasket (1)
33-5239
X
X
X
X
X
X
X
X
X
33-5237
X
X
X
X
33-5238
X
33-5240
X
X
X
X
62
DR600-800 1/8” Red
Gasket for Mixing
Chamber
33-0057 X X X X X X X
63
Air Inlet to Fan Adapter
16-0016
X
64
RG175 Fan Gasket
33-0038
X
65
DR300-400 1/8” Red
Gasket
33-0058 X X X
66
Air Inlet to Fan Adapter
16-0015
X
X
X
67
RG148 Fan Gasket
33-0037
X
X
X
68
Stainless to Plastic
Adapter
4” to 4”, 300142 X X X
5” to 6”, 300143
X
X
6” to 6”, 300144
X
X
X
7” to 8”, 300145 X X
8” to 8”, 300146
X
X
69
Wire Harness
77-0038
X
70
1” White Ceramic Gasket
(Baffles, primary wrap)
X
71
2” White Ceramic Gasket
(Stiffener, primary ring)
X
72
Black Viton Solid Gasket
(Secondary heat
exchanger)
X
73
Black Viton Foam Gasket
(Secondary wrap)
X
74
Snap Action Thermostat
EKA-114-58
X
75
Manual Shutoff Kit
50002653-001
X
X
X
X
Not shown in exploded view
Part
Recommended spare parts
