MULTIFUNCTION GAUGE (LCD) (570 MODELS)
5) 4WD I ndicator Lamp
When this indicat or is ON , it indicates
the 4WD system i s activated.
6) Low Fuel Le vel Indic a tor Lamp
When this indi cator is ON, it i ndi-
cate s that there is approximately 5 L
(1.3 U.S. ga l.) of fuel left in fuel tank.
7) Check Eng in e Indicator Lamp
When this indicat or is ON , it indicates
an engine fault code, look for a m es -
sage at the LCD dis play.
When this indica tor blinks, it i ndica tes
that the LIMP HOME mode is acti-
vate d.
Refer to
TROUBLES HOOT ING
section
for more details.
8) High Beam I ndicator Lamp
When this indicat or is ON , it indicates
that high beam is selected on the
headlights and that ignitio n key is in
ON w ith lights posi tion.
9) KM/H or MPH Indicator Lamp
The proper l a m p turns on to indicate
the unit the s peedometer uses.
Multifun ction Gauge
Modes
Speed Mode
In this mode, the m a in s cree n shows
the speed of the vehicle either in km/h
or in mph.
vdd2008-001-084
RPM M ode
In this mode, the m a in s cree n shows
the engine RPM.
vdd2008-001-089
Combined M ode
In this mode, the m a in s cree n shows
the speed of the vehicle and the engine
RPM.
vdd2008-001-085_a
1. Vehicle speed
2. Engine RPM
Odometer (OD)
Odom eter re cords the total distance
travelled either in miles or ki lometers .
88
