C&S CSDPR-V2-300 User Manual

Default First Screen
Two group of Protection Setting are available in CSDPR-V2 relay. User can select
One Group as Active Group. For setting below are simple steps for configuration:
Default Password for settings : “ 4-Times Enter Key”
MAIN DEFAULT SCREEN PAGE:
The very first Screen of the HMI shows the Measured Primary Current for all the
phases based on CT ratio.
L1 : 0000.0 A
L2 : 0000.0 A
<Menu 1>
(EDIT/VIEW PARAMETERS)
By using
the
scroll keys
select the
desired
menu and
press
ENTER.
Press Key
FACTORY MODE Setting are not for the users.
How to do Settings
*
Note : - * Menu Model Dependent
# / #EDIT VIEW
< > : For Active Group Selection of ParameterGROUP SELECT
< > : Protection Related Parameter MenuPROTECTION
< > : Cold Load Protection MenuCOLDLOAD PRT
< > : Fault Record MenuFAULT RECORD
< > : Event Record MenuEVENT RECORD
< > : Programmable Relay Assignment MenuDO ASSGNMNT
< > : Programmable Relay Reset MenuDO RESET
< > : Trip TypeTRIP TYPE
< RST TRIP CNT > : Reset Trip count Menu
< > : Display Options MenuDISPLAY OPTN
<BATTRY STATS > : MenuBattery Status
< > : Output Trip Test MenuTRIP TEST
< > : Communication 485 MenuCOMMN SETTNG RS
< > : Load Default MenuLOAD DEFAULT
< > : Clock Setting MenuEDIT RTC
< > : Password Change MenuCHNGE PSWORD
< > : Factory Setting MenuFACTORY MODE
< > : Relay Version MenuRELAY VERSON
← BACK
11
