Accuracy
Tripping times DMT : + 5% of the setting value or +40 mSec
with pre-fault IDMT : Accuracy as per IEC-255-3 (2xIs to 20xIs)
For VINV / NINV/RI : + 5% or + 40 mSec
For LINV/EINV/HV-Fuse : + 7.5% or + 60 mSec
Pickup accuracy +5% or +10mA
Boot-up time in < 100 mSec; (Event recorder enabled : 20mSec extra)
self powered mode
Output Contact (Relay Specs)
Number of relays 4
DO contacts (DO: 1, 2) DO1 & DO2 are user programmable
configurable & available for I>, I>>, le> & Ie>>, CBFP,
only with Auxiliary supply Unbalance (U0>), Remote DI, all faults
Relay contacts: 3, 4 Latch type of DO common for all
(available in all models) protection trip
Max. breaking capacity 1250VA / 150W resistive
500VA / 90W inductive
Max. breaking voltage 400V AC, 125 VDC
Max. continuous AC current 5A
Thermal Withstand Capacity
Thermal withstand Continuously 2.5A
capacity 10s 15A
for In=1A 1s 80A
