From Menu-1:
# TRIP TYPE #
TripO/P : TRIP-COIL
←BACK
Reset Count....?
YES NO CANCEL
# DISPLAY-OPTION #
MODE : AUTO OFF
←BACK
On selecting TRIP TYPE by pressing ENTER key, User
can see the list of parameter by using the scroll keys.
Press ENTER to select the desired Parameter & use
SCROLL keys to Edit the selected one.
If the user change any of the setting, It is required to save
the changes by pressing ENTER key and than selecting
YES option, after that entering the correct password to
save the setting or else to go to the previous menu by
selecting the other options & by pressing ENTER key.
On selecting RST TRIP CNT by pressing ENTER key,
User can Reset the Trip count by selecting the YES
option or else comes out from the menu by selecting the
other option.
On selecting DISPLAY OPTN by pressing ENTER key,
User can see the list of parameter by using the scroll
keys.
Press ENTER to select the desired Parameter & use
SCROLL keys to Edit the selected one.
If the user change any of the setting, It is required to save
the changes by pressing ENTER key and than selecting
YES option, after that entering the correct password to
save the setting or else to go to the previous menu by
selecting the other options & by pressing ENTER key.
From Menu-1:
From Menu-1:
# TRIP TEST #
LED/DO TEST
BREAKERTEST
LATCHRESET
←BACK
# BATTERY STATUS #
BATTERY : OK
←BACK
On selecting BATTRY STATS by pressing ENTER
key, User can see the status of the Battery, whether it
is OK or NOT.
On selecting TRIP TEST by pressing ENTER key,
User can see the list of parameter by using the scroll
keys.
Press ENTER to select the desired Parameter & use
SCROLL keys to perform the test.
If the user selects any of the option it will ask to
continue the Test, If the user selects the YES option
then Right/Left key are required to press to perform
the Test, else select other option and press enter to go
to the previous menu .
From Menu-1:
From Menu-1:
14
