Technical Data
Rear (RS-485) Communication Setting
Parameter Display Setting Range
Slave Address SLV Add 1-32
Baud Rate BD Rate 9600/19200
Parity Parity NONE/EVEN/ODD
General Data
Front (USB) Communication
Front Port: CSE protocol with CSE LIVELINK on mini USB cable type A/A
Measuring Input
Rated data Rated current IN (1A)
Frequency FN: 50/60 Hz
Measurement Measurement of Phase / Earth current starts from 5%
Rated auxiliary Universal L: (18V - 60V DC)
voltage UH H: (85V - 260V AC /
110V to 300V DC)
Rated supply for Normal voltage UN L: (18V - 60V DC)
DI input H: (85V - 260V AC /
110V to 300V DC)
Power consumption
of Aux supply Quiescent approx. 3W Operating approx. 6W
Dropout pickup ratio > 95 %
Phase / Earth VA Burden : (2.5VA @ Rated Current)
