22
5. Using your hand, tap lightly on
compression rod nut and rebound
knob assembly to disengage seals
on lowers. Now, completely unthread
compression rod nut and rebound
knob assembly and remove from
fork.
6. Lay fork face down on something
protective.
7. Grabbing the lowers and the upper
legs with a hand on each, pull and
separate *LEAVE LOWERS LAYING
FACE DOWN TO PREVENT THE
LOSS OF OIL (If oil loss is excessive,
reference service manual for oil
specifications).
8. Clamp the separated uppers in a
bike stand with the legs facing up.
Using a 22mm wrench, unthread air
seal head on air side leg.
Internal Travel Adjustment
8.
5.
7.
Air Seal Head
