20
CT-2000 Instruction Manual
Test
Test Purpose
A/D
Calibrates analog-digital converter and verifies function and consistency.
Voltage Levels
Verifies power supply voltage levels (positive and negative).
Figure 19 illustrates the LCD sequence for a normal self-test:
Figure 19: Normal Test Sequence Display
If the self-test sequence is accomplished successfully, the CT-2000 commences normal operations.
