Bit
7 6 5 4 3 2 1 0
Timeout Period of TX and RX
8 minutes 0 * * * * * 0 0
16 minutes * * * * * * 0 1
32 minutes 0 * * * * * 1 0
64 minutes 0 * * * * * 1 1
Bit
7 6 5 4 3 2 1 0
TX Timeout Period
(Image Mode: Letters)
8 minutes 0 * * * * * 0 0
16minutes 0 * * * * * 0 1
32minutes 0 * * * * * 1 0
64 minutes 0 * * * * * 1 1
Bit
7 6 5 4 3 2 1 0
TX Timeout Period
(Image Mode: Other than Letters)
8 minutes 1 * * * 0 0 * *
16 minutes 1 * * * 0 1 * *
32 minutes 1 * * * 1 0 * *
64 minutes 1 * * * 1 1 * *
Bit
7 6 5 4 3 2 1 0
RX Timeout Period
8 minutes 1 * 0 0 * * * *
16 minutes 1 * 0 1 * * * *
32 minutes 1 * 1 0 * * * *
64 minutes 1 * 1 1 * * * *
* 0 or 1 (depending on each setting)
1-35
