9. Main Specifications
Note: In the International System of Units (SI), the expression 1 D (diopter) = 1 m
-1
.
Type Mydriatic type
Field angle 50°/43° (digital)
Magnification view 1.1
× (Image size on the sensor)
Image magnification of observation 10
×
Diameter of pupil required ø5.2 mm or more
ø4.3 mm or more (when using the small pupil function)
Working distance 35 mm
Patient’s diopter range -10 to +15 D (without compensation lens)
-31 to -7 D (when using negative compensation lens)
+11 to +33 D (when using positive compensation lens)
Photographer’s diopter compensation
range
±5 D
Flash intensity Linked to photography mode
Can be set manually
Camera Canon EOS digital camera (sold separately)
Eye fixation lamp External eye fixation lamp
Internal Eye Fixation Target (sold separately)
Working range
Stage horizontal movement 110 mm side to side, 65 mm front and back
Main unit vertical movement 30 mm
Chin rest vertical movement 60 mm
Panning 30° to the right and left
Tilting 15° up and 10° down
Environment requirements
Use Temperature: 10°C to 35°C
Humidity: 30% to 80% RH (no condensation)
Atmospheric pressure: 800 hPa to 1060 hPa
Storage Temperature: -10°C to 55°C
Humidity: 10% to 95% RH (no condensation)
Atmospheric pressure: 700 hPa to 1060 hPa
Transportation Temperature: -30°C to 60°C
Humidity: 10% to 60% RH (no condensation)
Atmospheric pressure: 700 hPa to 1060 hPa
Rated power supply AC 100 V to 240 V, 50/60 Hz, 7 to 3 A
Dimensions 320(W) × 531(L) × 576(H) mm
Mass 26 kg (including a EOS digital camera 0.8 kg)
