Connection Diagram
Canon
NFC-compatible camera/
camcorder (p.22)
Another Connect
Station
(p.49)
Access point
or
router
(p.16, 18, 57)
Smartphone/
Tablet/
Computer (p.40)
Web service
(p.46)
(LAN cable)
TV set (p.14) External hard disk
(p.61)
Canon camera/
camcorder (p.25)
AC adapter
(p.15)
CF card
(p.24)
Printer
(p.38)
SD card
(p.24)
(HDMI cable) (USB cable) (Interface cable)
Internet
* Not required when Connect
Station is connected to the
access point via a wireless LAN.
USB hubs are not supported.
Operation cannot be guaranteed if a USB extension cable is used.
