6.
Slide the right paper guide (C) to align the paper guides with both sides of the paper stack.
Do not slide the paper guides too hard against the paper. The paper may not be fed properly.
* The above figure shows the printer with the paper output tray raised.
Note
• Do not load sheets of paper higher than the load limit mark (F).
• Keep the paper stack height below the tabs (G) of the paper guides.
* The above figure shows the printer with the paper output tray raised.
7. Grab right and left sides of front cover and push cassette back until arrow ( ) on front
cover is aligned with edge of printer.
After pushing the cassette back properly, the paper information registration screen appears on the LCD.
84
To Next Page
