27
Before You Star t
1
Mounting and Detaching a Lens
Mounting a Lens
Remove the caps.
•
Remove the rear lens cap and the body cap by
turning them as shown by the arrow.
1
Attach the lens.
•
Align the red dots on the lens and camera and turn
the lens as shown by the arrow until it snaps in
place.
2
On the lens, set the focus mode switch
to <AF>.
•
If the focus mode switch is set to <MF> (or <M> on
older lenses), autofocus will not operate.
3
Remove the front lens cap.
4
Lens mount index
Detaching the Lens
While pressing the lens release button,
turn the lens as shown by the arrow.
•
Tu rn the lens until the red dot is at the top, then
detach the lens.
•
Since the EOS 10D’s image coverage is smaller than the
normal 35mm film format, the EF lens attached to the
camera will have a telephoto effect equivalent to 1.6 times
of the marked focal length.
•
AF stands for autofocus.
•
MF or M stands for manual focus.
•
Be careful not to lose the lens caps or body cap.
EOS 10D image field
(22.7 x 15.1 mm / 0.89 x 0.59 in)
35 mm image field
(36 x 24 mm / 1.42 x 0.94 in)
To Next Page
