2
Open the Top Cover.
3
Pinch the Belt together, insert it between the Belt
Stopper, and affix the Belt Stopper to the Carriage
Shaft.
Important
•
Do not touch the Linear Scale (a) or Carriage
Shaft (b). This may stain your hands and dam-
age the printer.
Note
• Here, the Belt Stopper is the one that was removed and stored after initial installation.
iPF6450
Preparing to Transfer the Printer
Basic Guide
Printer Relocation Preparing to Transfer the Printer
81
To Next Page
