FIGURE &
KEY No.
PART NUMBER RANK QTY DESCRIPTION REMARKS
10- 1 QC1-9941-000 1 CAM, SWING ARM LOCK
2 QL2-1450-000 1 PR LIFT SHAFT ASS'Y
3 QM2-3890-000 1 PAPER GUIDE UNIT
4 QM2-3886-000 1 PRESSURE ROLLER ASS'Y
5 QM3-1273-000
󲩷
1 CARRIAGE LIFT SENSOR UNIT
6 QC2-0037-000 1 CARRIAGE LIFT GEAR BASE UNIT
7 QC2-1873-000 1 GEAR, INPUT CARRIAGE LIFT
8 QC1-6212-000 1 GEAR, IDLER CARRIAGE LIFT
9 QC2-0039-000 1 SPRING, TORSION
10 QC2-0038-000 1 GEAR, OUTPUT CARRIAGE LIFT
11 QC2-0040-000 1 LEVER, SWING ARM LOCK
12 QM3-1274-000 1 PE SENSOR UNIT
13 QK1-1502-000 1 MOTOR, PAPER FEED
14 QC1-9939-000 1 BUSHING
15 QC2-0475-000 1 FILM, TIMING SLIT DISK
16 QC1-6230-000 1 BELT, PAPER FEED
17 QL2-1490-000 1 FEED ROLLER ASS'Y
18 QC1-6225-000 1 GEAR, EJECT
19 QM3-1271-000 1 TIMING SENSOR UNIT
