SCREW & WASHER LIST
FIGURE &
KEY No.
PART NUMBER
RANK
QTY
DESCRIPTION
REMARKS
S - 1 XB1-2300-405 SCREW, MACH.BH, M3X4
2 XA9-1258-000 SCREW, TAP, WASHER HEAD, M3X12
3 XB2-4300-605 SCREW, W/WASHER, M3X6
4 XB4-7300-805 SCREW, TP, BH3X8
5 XA9-1437-000 SCREW, BIND, M2.6X4(RED)
6 XB1-2200-405 SCREW, M2X4
