APPENDIX 2: EEPROM INFORMATION PRINT
<How to read EEPROM information print>
Print sample:
iP4300 JPN V1.00 ST=2006/05/27-18:30 LPT=2006/06/09-09:09
ER(ER0=1000 ER1=5100) P_ON(S=00009) MSD(015)
IF(USB1=0) PC(M=002 R=000 T=001 D=009 C=009)
D=004.5
TPAGE=00216
CLT(BK=2006/05/29-18:30 CL=2006/05/30-18:30)
CH=002 CT(PBK=001 BK=001 Y=002 M=001 C=001)
IS(PBK=1 BK=0 Y=1 M=1 C=1)
A_REG=1
M_REG=0
UR(A(BKoe)=000 B(Coe)=000 C(SCoe)=000 D(CLbi)=000 E(SCLbi)=000 F(C-SC)=000
G(BK-CL)=000 H(BKbiPP)=000 I(CLbiPP)=000 J(SCLbiPP)=000
K(NZctr)=000 L(NZedge)=000 M(CLbiHiReso)=000 N=(SCLbiHiReso)=000
CDIN(PB=000 OPB=000)
PAGE(All=00083 PP=00035 HR+MP=00003 PR+SP+SG =00000 GP =00000 PC=00000 EV=00000)
UCPAGE(All=00083 PP=00035 HR+MP=00003 PR+SP+SG =00000 GP =00000 PC=00000 EV=00000)
BPPAGE(All=00083 BPSP=00003 PC=00000)
CDPAGE(All=00000)
EDGE=00083 L=00000 CDR=00000
CDRP=(-00005,-00029) CDRS=(0101) LF=0 LM=(ASF_R:00 UT_F:00 UT_R:00)
INK_OFF(PBK=0 BK=0 Y=0 M=0 C=0)
Head TempBK=34.5 Head TempC=30.5 Env Temp=27.0
Printed items:
1. Model name 2. Destination 3. ROM version 4. Installation date 5. Last printing time
6. Operator call/service call error record 7. Power-on count (soft) 8. Longest period where
printing stops (days)
9. Connected I/F (USB1) 10. Purging count (manual/deep cleaning/timer/dot count/ink tank
replacement)
11. Ink amount in the ink absorber
12. Total print pages (TPAGE = total page)
13. Cleaning time (BK/CL)
14. Print head replacement count 15. Ink tank replacement count (PhotoBK/PigBK/Y/M/C)
16. Ink status (PhotoBK/PigBK/Y/M/C) => 0 (High) / 1 (Middle) / 2 (Low) / 3 (Empty)
17. Automatic print head alignment by user
18. Manual print head alignment by user
19. User print head alignment values
(BKoe/Coe/SCoe//CLbi/SCLbi/C-SC/BK-CL/BKbiPP/CLbiPP/SCLbiPP/NZctr/NZedge/CLbiHiReso/
SCLbiHiReso)
20. Camera Direct Print-supported device connection record (PB = Canon PictBridge-supported
camera, OPB = Other PictBridge-supported camera)
21. ASF feed pages (total, plain paper, High Resolution Paper & Matte Photo Paper, Photo Paper
Pro & Photo Paper Plus Glossy & Photo Paper Plus Semi-gloss, Glossy Photo Paper, postcard,
envelope)
22. U-turn cassette feed pages (total, plain paper, High Resolution Paper & Matte Photo Paper,
Photo Paper Pro & Photo Paper Plus Glossy & Photo Paper Plus Semi-gloss, Glossy Photo Paper,
