2.1.2 Rated Outputs from the Power Supply PCB
The levels of outputs form the DC power supply of the full-time ON system are as fol-
lows:
Output
Connector
Output voltage
tolerance
Rated output voltage
Rated output current
Activation level of
overcurrent protection
mechanism
3VS1
CN1-11
CN1-13
CN2-8
CN2-9
±3%
3.45V
4.3A
8.0A
3VS2
CN1-15
CN1-17
CN1-19
CN1-20
±3%
3.45V
4.3A
8.0A
5VS
CN2-12
CN2-13
±5%
5.05V
1.9A
4.0A
12VS
CN1-1
±5%
12V
0.6A
3.0A
T08-201-02
The levels of outputs form the DC power supply of the remote ON/OFF system are as fol-
lows:
Output
Connector
Output voltage
tolerance
Rated output voltage
Rated output current
Activation level of
overcurrent protection
mechanism
3VR
CN1-7
±5%
3.35V
0.3A
4.0A
5VR
CN1-6
±5%
5.05V
1.0A
3.0A
24VR1
CN3-1
CN3-2
±5%
24V
5.0A
8.0A
24VR2
CN2-18
CN2-27
±5%
24V
5.0A
8.0A
T08-201-03
* The above levels apply when the AC input is between 85 and 135 V for the 120V model
and between 187 and 264 V for the 230V model.
