3.7 Table Control elements
3.7.1 Directions of Movement
The figure below shows the directions of the table movement.
X
Y
Z
Front
Fig. 3-36 Directions of movement, Table
Z
Vertical movement
Y
Lateral movement
X
Longitudinal movement
3.7.2 Power Indication
The green light indicates that the System is active.
4017
Fig. 3-37 Power indication light
