Procedure
Settings front side What to enter
X elongation (0.01%) The image is elongated or shrunk in incre-
ments of 0.01%.
A value > 0 elongates the image by moving the
trailing edge of the image to the right:
• The length of the image in the feed direction
increases.
• The distance between the leading edge of
the sheet and the image on the sheet re-
mains the same.
• The circles on the right-hand side of the ver-
ification chart move to the right (trailing
edge).
A value < 0 shrinks the image by moving the
trailing edge of the image to the left:
• The length of the image in the feed direction
decreases.
• The distance between the leading edge of
the sheet and the image on the sheet re-
mains the same.
• The circles on the right-hand side of the ver-
ification chart move to the left (leading
edge).
Settings back side What to enter
X elongation (0.01%) The image is elongated or shrunk in incre-
ments of 0.01%.
A value > 0 elongates the image by moving the
trailing edge of the image to the right:
• The length of the image in the feed direction
increases.
• The distance between the leading edge of
the sheet and the image on the sheet re-
mains the same.
• The dots on the right-hand side of the verifi-
cation chart move to the right (trailing
edge).
A value < 0 shrinks the image by moving the
trailing edge of the image to the left:
• The length of the image in the feed direction
decreases.
• The distance between the leading edge of
the sheet and the image on the sheet re-
mains the same.
• The dots on the right-hand side of the verifi-
cation chart move to the left (leading edge).
