1-9
Before Using the VB-C50FSi/VB-C50Fi
System Components and Their Operation
Front
LAN status LED
The LED blinks during communication.
100Base-TX .......................... Green
10Base-T ............................... Orange
* You can set the LED to always light
up even during communication. In
this case, you can select from a
green, orange or red light color. You
can also set the LED not to light up
(→ P.3-27).
Screw hole for arm mounting
Note
The only outwardly visible difference between the VB-C50FSi and VB-C50Fi is the
model name printed on the casing. The names and functions of the components are
the same.
