IR Clear [CLR]
Use this function to delete all IR codes stored on the Amp 5�1�
To delete IR commands please do the following:
1
To enter the Menu, press the "M" button.
2
Use the " " or " " button to navigate to the menu System Setup [SYS] and confirm with the "OK" button�
3
Use the " " or " " button to select the IR Menu [IRM] and confirm with the "OK" button�
4
Use the " " or " " button to select the menu item IR Clear [CLR] and confirm with the "OK" button�
5
"Reset All" appears on the screen and [YES] appears on the display� Press the OK button on the Canton Smart remote to delete the sto-
red commands� The screen will display "Please Wait"� The system will then return to the IR menu [IRM]�
6
To cancel the operation, press the "M" button or press "OK"�
HDMI CEC [CEC]
Consumer Electronics Control is a cross-market standardized protocol for controlling devices connected to the HDMI® inputs/outputs� By default
this function activated [ON]�
The CEC functions supported by the Smart Amp 5�1 are:
- One touch Play: By pressing the “Play” button of e�g� a Blu-Ray player the Amp 5�1 switches on automatically and changes to the
corresponding HDMI® input�
- System Standby: With the TV switched on and then turning it into standby mode by pressing the “Power” key the Amp 5�1 also goes
automatically into standby mode�
Note: Depending on the programming of the TV device, the Amp 5�1 can also be automatically activated with the TV�
- Volume/Mute: The volume of the Amp 5�1 can be operated using the Mute and Volume buttons of the TV remote control�
To activate/deactivate this function please proceed with the following steps:
1
To enter the Menu, press the "M" button�
2
Use the " " or " " button to select the menu item System Setup [SYS] and confirm with the "OK" button�
3
Use the " " or " " button to select the menu item HDMI CEC [CEC] and confirm with the "OK" button�
4
Use the " " or " " button to select "OFF" [OFF] to disable the CEC function resp� "ON" [ON] to enable the function�
5
Press the "M" button to exit this menu item�
Notes: •Many device manufacturers have developed their own protocols for controlling their devices based on the CEC standard�
This can mean that the functions described above only function partially or does not function at all�
•In order to avoid conflicts when controlling the Smart Amp 5�1, the “Volume +/–“, “Mute” and “Power” buttons on the TV remote control
should not be learned through the IR learn function of the amplifier when using the CEC function� Delete the codes if necessary�
Standby Mode [STB]
This function controls, how the Amp 5�1 powers up resp� down – manually or automatically, partly dependent on an incoming audio signal� The Amp
5�1 supports the following functions:
• ECO [ECO]: If ECO is selected, the Amp 5�1 enters standby mode after 20 minutes without any detected audio signal at the selected input and
needs to be powered up manually using the remote control�
• Network [NSB]: If Network [NSB] is selected, the Amp 5�1 must be turned on manually and will automatically enter standby after 20 minutes
without detected audio at the selected input� However, there is a difference to the ECO mode, as described below� Network [NSB] is the
default setting of the Amp 5�1�
• Auto [AUT]: If Auto is selected, the Amp 5�1 turns on automatically if an audio signal is detected at the input recently used� If no signal is
detected any longer, the Amp 5�1 enters standby mode after 1 minute (at the digital inputs Optical, Coaxial and Bluetooth) resp� 15 minutes
(at the analog input Line [AUX])�
• Manuell [MAN]: If Manual is selected, the Amp 5�1 stays active permanently and must be powered up and down manually, using the
remote control�
If ECO is selected, all wirelessly connected speakers will be powered down automatically, but each speaker must be powered up individually� This is
the operation mode with the lowest standby power consumption� All the other modes Network, Auto, and Manual provide an automatic power up
function for all wirelessly connected speakers when powering up the Smart Amp 5�1 (Master Device)�
Notes: •If the standby mode is set to Auto [AUT] and the Amp 5�1 is set to standby mode using the “ON/Standby” key of the remote control, it is
not possible for the Amp 5�1 to switch on automatically� To use the Auto mode of the Amp 5�1 as intended, do not power down the Amp 5�1
using the On/Standby key but always wait until the Amp 5�1 powers down, automatically�
•To avoid an unintentional power-up of the Amp 5�1 using the analogue input, the threshold value has been set quite high� To make sure the
Amp 5�1 powers up correctly, please set the output level of your analog audio source to a high level (but not more than 2Vrms)�
