IR Menu [IRM]
This menu includes all functions relevant for the infrared operation of the amplifier� It consists of three submenus�
IR Learn [IRL]
The system can learn the infrared codes of your TV remote control and therefore allows you to control the functions of the amplifier and your TV
via one remote control� You can allocate any key of the TV remote control to your Amp 5�1� When choosing a key, make sure that the instruc-
tions for the amplifier do not conflict with the TV� We recommend that you deactivate the internal loudspeakers of the TV once the amplifier is
connected� Then you can use the volume keys for the Amp 5�1�
To learn the IR codes of a third party remote please do the following steps:
1
To enter the menu, press the "M" button�
2
Use the " " or " " button to navigate to the menu System Setup [SYS] and confirm with the "OK" button
3
Select the IR Menu [IRM] by using the " " or " " buttons and press the "OK" button to confirm�
4
Confirm the first menu item Sleep Timer [SLP] with the "OK" button� "Please press key you want to learn" appears on the screen, the display
flashes [IRL]�
5
Please press the desired function on the Canton Smart remote control�
Note: The IR codes of a TV remote can be assigned to all buttons of the optionally available Canton Smart remote alike�
6
"Press the new button" will be shown on the screen with the name of the selected key (e�g� "Volume +") below� The display indicates the
selected function as well (e�g� V+])�
7
Within 15 seconds, press the key you wish to allocate to this function on the TV remote�
8
Once the IR command has been successfully allocated, the display shows [OK] resp� the OSD shows "Success" and you can continue with the
programming of the next function, e�g� “Volume –“�
9
If the display shows [FAI] and the name of the selected key disappears, the allocation has failed or the time exceeded� Now you need to
repeat steps 5 to 8� Please try a lower or higher distance between the Amp 5�1 and the TV remote control in case the process fails again�
Alternatively, try to press the key on the TV remote shorter or longer�
10
To exit the IR Learn menu, press and hold the "M" button for 3 seconds� After one minute without input, the system automatically returns to
the IR menu�
Notes: •The “On/Standby” key has a dual function� Press it once and the display shows [ON] which allows the "on" function to be
programmed� If the key on is pressed twice in quick sequence, the display shows [STB] and the "Standby" function can be learned�
If your TV remote control has only one key for the “On” and “Standby” functions, both the “On” and “Standby” function must still be
allocated with this command�
•Due to the variety of infrared codes it is not possible to guarantee that every IR remote control signal can be learned by the Smart
Amp 5�1� Signals from radio frequency (RF) remote controls cannot be learned in general!
Direct Input Learn [DIL]
This function allows the user a direct selection of the signal inputs if using a third party remote control� In addition to the INPUT UP( ) and IN-
PUT DOWN( ) function, you can directly select the signal inputs (e�g� ARC) when using your TV or universal remote control� That means you can
allocate the desired input to a key on your remote control�
To learn the relating IR codes please do the following steps:
1
To enter the menu, press the "M" button�
2
Use the " " or " " button to navigate to the menu System Setup [SYS] and confirm with the "OK" button�
3
Select the IR Menu [IRM] by using the " " or " " buttons and press the "OK" button to confirm�
4
Choose the function Direct Input Learn [DIL] by using the " " or " " button and press the "OK" button to confirm�
5
"Press the new button" will be shown on the screen with the name of the first input "BDP"� The display flashes [HD1]� Now you can allocate a
key on your TV or universal remote to the input BDP [HD1]�
Note: If you press this key on the remote control while the Amp 5�1 is in normal mode, the system switches directly to the HD1 (BDP) input�
6
Press the desired key on the remote control� If the infrared code has been successfully stored by the system, [OK] is shown briefly in the
display resp� "Success" on the screen, followed by the next input�
7
If the code could not be learned, [FAI] appears briefly on the display resp� "Failed" appears on the screen to indicate that no code has been
stored� In this case [HD1] will still be displayed� Please try a lower or higher distance between the Amp 5�1 and the TV remote control in case
the process fails again� Alternatively, try to press the key on the TV remote shorter or longer�
8
If you do not want to assign a button to input HD1, you can select the next input (in this case HD2) by pressing the " " button� The " " button
takes you to the previous input�
9
If you do not press any button on the TV remote control within 15 seconds, the system returns to the IR Menu�
10
The BT input is the last entry in the list� After this input the system jumps back to the IR menu�
Note: Due to the variety of infrared codes it is not possible to guarantee that every IR remote control signal can be learned by the Connect 5�1�
Signals from radio frequency (RF) remote controls cannot be learned, generally!
