Canton Smart Amp 5.1 Operating Instructions

3
33
English
32
English
Device Heights [DHE]
In case of using Dolby Atmos® enabled speakers that direct the sound upwards to the ceiling it is necessary to set the heights of these speakers (for
example when placed on top of normal speakers or on a nearby surface) to achive an optimal spatial surround impression (3D sound)� The heights
can be set in 0�1m steps for the front and rear "Upfire" speakers seperately, with 1m being the factory setting�
To set the device heights please do as follows:
1
To enter the menu, press the "M" button.
2
Confirm the first menu item Speaker Setup [SPS] with the "OK" button�
3
Use the " " or " " button to select the menu item Device Heights [DHE] and confirm with the "OK" button�
4
Use the "+" resp� the "–" key to select the desired pair of speakers (front or rear) and confirm your selection with the "OK" button�
5
Use the "+" resp� the "–" key to set the height and confirm your selection with the "OK" button� Repeat this steps in case for the other pair of
speakers�
6
Confirm and exit the menu item by pressing the "M" button�
Note: The menu item Device Heights [DHE] is only available and not grayed out if Top Front-speakers have been activated in the menu
"Speaker Config" [SPC]�
Sound Setup [SND]
In this menu you can adjust the tone control settings for bass, mid and treble� These adjustments are identical to the ones that can be made using
the Sound-button on the Smart remote�
To adjust the settings for the tone control settings, please do as follows:
1
To enter the menu, press the "M" button�
2
Enter the first menu item Speaker Setup [SPS] and press the "OK" button�
3
Use the " " or " " button to navigate to the item Sound Setup [SND] and confirm with the "OK" button�
4
Use the " " or " " button to navigate to the paramter you want to adjust and use the "+" or "–" button to select the desired gain given in dB�
4
Press the "M" button to exit this menu item�
2. System Setup [SYS]
The second item in the main menu is the System Setup� It contains the following menu items:
•Sleep Timer [SLP]
•IR Menu [IRM]
–IR Learn [IRL] –Direct Input Learn [DIL] –IR Clear [RES]
•HDMI CEC [CEC]
•Standby Mode [STB]
•Input Config [INP]
•Analog Gain [OFS]
•Input Select [SEL]
•Lipsync [LIP]
•Max Volume [VOL]
•Playmode [PLM]
•3D Audio [3D]
•Display Setup [UI]
–Language [LAN] –LED Flashing [LED] –Input Stream Display [ISD] –Slave Display [SUI]
•Factory Reset [RES]
–OTA Recovery [OTA]
Sleep Timer [SLP]
If this function is enabled, the system shuts down to standby mode after a specified time� You can select 15, 30, 45 or 60 Minutes�
If the value OFF is selected, the function is disabled�
To adjust the shut down time, please follow the next steps:
1
To enter the menu, press the "M" button.
2
Use the " " or " " button to navigate to the menu System Setup [SYS] and confirm with the "OK" button�
3
Confirm the first menu item Sleep Timer [SLP] by pressing the "OK" button�
4
Select the desired time using the + or – keys�
5
Press the "M" button to exit this menu item�
Note: The Sleep Timer will be disabled automatically after a power down� That means the shut down time must be selected again after
every power up sequence in order to use this function�

Canton Smart Amp 5.1 Specifications

General

Video in	3x HDMI
Video out	1x HDMI
Ethernet LAN (RJ-45) ports	1
Speakers connectivity type	-
Product color	Black
Volume control	Touch
Cables included	AC
Treble adjustment	Yes
Connectivity technology	Wired & Wireless
Audio decoders	DTS-HD, Dolby Atmos
Audio output channels	- channels
Peak power per channel	600 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %

Weight and Dimensions

Depth	154 mm
Width	245 mm
Height	120 mm
Weight	5240 g
