Canvas 088-1760-6 User Manual

18 19
PRODUCT NO. 088-1760-6
ASS E MBLY
Step 21
Requires F1, L1, L2, L3, L4, M1, M2, M3, M4, BB, CC
Attach other end of each beam (L1, L2, M1, M2) to Slanting bar for large roof
(F1) using M6x15 screws (CC) and M6 washers (BB).
CC
CC
BB
F1
M1
L1
M2
L2
BB
Step 20
Requires G, L1, L2, M1, M2, BB, CC
Attach one end of each beam (L1, L2, M1, M2,) to Middle bar for large roof (G)
using M6x15 screws (CC) and M6 washers (BB).
M1
L1
G
CC BB
BB
CC
M2
L2
BB
CC
BB
CC
