PRODUCT NO. 088-1760-6
ASS E MBLY
Step 25
Requires F1, Y1, Y2, Y3, Y4, BB, CC
Attach other end of pipes (Y1, Y2, Y3, Y4) to Slanting bar for large roof (F1)
using M6x15 screws (CC) and M6 washers (BB).
Y1 Y2
BB
CC
F1
Y3 Y4
Step 24
Requires G, Y1, Y2, Y3, Y4, BB, CC
Attach one end of pipes (Y1, Y2, Y3, Y4) to Middle bar for large roof (G) using
M6x15 screws (CC) and M6 washers (BB).
CC
CC
G
BB
BB
Y1 Y3
Y2 Y4
BB
BB
CC
CC
