REMOTE CONTROL
At first ignition, keep pressed the lighting button for 5 seconds.
Remote control used for the operation of island extractors:
Technical Data
Alkaline battery powered : 12 V mod. 23 A
Operating frequency : 433.92 Mhz
Combinations : 32.768
Max. consumption : 25 mA
Operating temperature: -20 ÷ + 55 °C
Dimensions : 120 x 45 x 15 mm
OPERATION
The transmitter is equipped with 5 buttons for cooker hood management, as
specified below:
Light ON/OFF command.
Motor ON (speed level 1) / OFF command.
Reduce speed.
Increase speed.
10-minute timer.
The set extraction speed is indicated by the LED in the extraction perimeter channel.
To each color generated by the LED, it corresponds a specific speed, as shown
below:
First speed WHITE
Second speed BLUE
Third speed DARK BLUE
Fourth speed RED
