Caple DD606BK - Grease Filter Removal, Installing the Activated Charcoal Filter

Instruction manual DD606BK
13
Please keep this instruction manual for future reference
GREASE FILTER REMOVAL,
INSTALLING THE CHARCOAL FILTERS
The removal and fitting of the grease and charcoal filters need to be carried out with the
downdraft in the open position. To open the downdraft, push the ‘1’ key. Then remove the front
panel, pushing the upper part of each side at the same time. The panel will drop forwards to make
it possible to access the grease filters (Fig. 6). Remove the grease filters to access the charcoal
filters (Fig. 12). The replacement of the charcoal filters has to be carried out accordingly to the
effective use of the Downdraft, and in any case they should be replaced at least once every
6 months.
NOTE:
Replacement filters (CAP27CF) can be purchased at www.caple.co.uk. After having replaced the
filters, reinstall the front stainless steel panel, otherwise the Downdraft is not enabled to function.
