Instruction manual DD606BK
16
Please keep this instruction manual for future reference
OPERATING THE DOWNDRAFT EXTRACTOR
10
MODEL DD911
A: Light ON/OFF key
The light switches on and off only when the
carriage is fully OPEN.
Pressing this button with the carriage closed
will cause the carriage to open and then the
light will switch on .
The button also serves to switch off the light
if it is on.
B:
ON/OFF key
This starts the extraction carriage upward
movement and when it is fully open, it sets the
second extraction speed.
With the carriage open: it switches off the mo-
tor and if on, the light; then it retracts the ex-
traction carriage.
C:
(-) Key
This reduces the speed of the extractor motor
from the 4th speed until the motor switch-
es off, without closing the pull-out car-
riage.
D:
Indicators
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
• This signals that all filters have been satu-
rated by all LEDs switching on.
E:
(+) Key
This increases the speed of the extractor mo-
tor, from 1st to 4th speed, without moving the
extractor panel.
F:
Timer
10 min after setting, it serves to stop the ex-
tractor motor, close the carriage and switch
the lights off, if they are on. The set function is
signalled by the flashing LEDs “D” for the set
speed. The timer can be cancelled by press-
ing the key again.
Other functions:
Automatic turn off:
After 4 hours of continuous working from
the last function selection, the appliance
turns off and closes automatically.
Grease filters saturation:
After 30 hours of working, the speed indica-
tors “D” will all flash simultaneously, signaling
the grease filters saturation.
To reset this alarm, hold down the “TIMER”
button for at least 3 seconds, while the car-
riage is open.
Calibration:
The cooker hood carries out its self
calibration every 3 complete cycles of its
extractable unit.
By pushing the “TIMER” key 6 times consec-
utively (MAX break between one push and the
other is 3 sec.) all the leds will flash and the
calibration will be reset.
After the next 3 cycles the downdraft will carry
out its self calibration.
Stand-by:
When the extractable unit is closed and the
light is switched off, the control panel,
after 6 seconds, activates the stand-by
function, reducing the brightness of the leds.
This function can be stopped by pressing ON/
OFF or LIGHT key.
How the downdraft works
OFF KEY
This serves to close the extraction panel either completely from any position that is more than
180mm from the hob. When the extraction panel is being closed, it will remain in operation until it
reaches 180mm above the hob. Below this height, the extraction function will switch
off automatically.
10
MODEL DD911
A: Light ON/OFF key
The light switches on and off only when the
carriage is fully OPEN.
Pressing this button with the carriage closed
will cause the carriage to open and then the
light will switch on .
The button also serves to switch off the light
if it is on.
B:
ON/OFF key
This starts the extraction carriage upward
movement and when it is fully open, it sets the
second extraction speed.
With the carriage open: it switches off the mo-
tor and if on, the light; then it retracts the ex-
traction carriage.
C:
(-) Key
This reduces the speed of the extractor motor
from the 4th speed until the motor switch-
es off, without closing the pull-out car-
riage.
D:
Indicators
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
• This signals that all filters have been satu-
rated by all LEDs switching on.
E:
(+) Key
This increases the speed of the extractor mo-
tor, from 1st to 4th speed, without moving the
extractor panel.
F:
Timer
10 min after setting, it serves to stop the ex-
tractor motor, close the carriage and switch
the lights off, if they are on. The set function is
signalled by the flashing LEDs “D” for the set
speed. The timer can be cancelled by press-
ing the key again.
Other functions:
Automatic turn off:
After 4 hours of continuous working from
the last function selection, the appliance
turns off and closes automatically.
Grease filters saturation:
After 30 hours of working, the speed indica-
tors “D” will all flash simultaneously, signaling
the grease filters saturation.
To reset this alarm, hold down the “TIMER”
button for at least 3 seconds, while the car-
riage is open.
Calibration:
The cooker hood carries out its self
calibration every 3 complete cycles of its
extractable unit.
By pushing the “TIMER” key 6 times consec-
utively (MAX break between one push and the
other is 3 sec.) all the leds will flash and the
calibration will be reset.
After the next 3 cycles the downdraft will carry
out its self calibration.
Stand-by:
When the extractable unit is closed and the
light is switched off, the control panel,
after 6 seconds, activates the stand-by
function, reducing the brightness of the leds.
This function can be stopped by pressing ON/
OFF or LIGHT key.
How the downdraft works
(-) KEY
Reduces the speed of the extraction motor. This button only works when the height of the
extraction panel is more than 180mm from the hob.
INDICATORS
Indicates the chosen level of extraction speed.
10
MODEL DD911
A: Light ON/OFF key
The light switches on and off only when the
carriage is fully OPEN.
Pressing this button with the carriage closed
will cause the carriage to open and then the
light will switch on .
The button also serves to switch off the light
if it is on.
B:
ON/OFF key
This starts the extraction carriage upward
movement and when it is fully open, it sets the
second extraction speed.
With the carriage open: it switches off the mo-
tor and if on, the light; then it retracts the ex-
traction carriage.
C:
(-) Key
This reduces the speed of the extractor motor
from the 4th speed until the motor switch-
es off, without closing the pull-out car-
riage.
D:
Indicators
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
• This signals that all filters have been satu-
rated by all LEDs switching on.
E:
(+) Key
This increases the speed of the extractor mo-
tor, from 1st to 4th speed, without moving the
extractor panel.
F:
Timer
10 min after setting, it serves to stop the ex-
tractor motor, close the carriage and switch
the lights off, if they are on. The set function is
signalled by the flashing LEDs “D” for the set
speed. The timer can be cancelled by press-
ing the key again.
Other functions:
Automatic turn off:
After 4 hours of continuous working from
the last function selection, the appliance
turns off and closes automatically.
Grease filters saturation:
After 30 hours of working, the speed indica-
tors “D” will all flash simultaneously, signaling
the grease filters saturation.
To reset this alarm, hold down the “TIMER”
button for at least 3 seconds, while the car-
riage is open.
Calibration:
The cooker hood carries out its self
calibration every 3 complete cycles of its
extractable unit.
By pushing the “TIMER” key 6 times consec-
utively (MAX break between one push and the
other is 3 sec.) all the leds will flash and the
calibration will be reset.
After the next 3 cycles the downdraft will carry
out its self calibration.
Stand-by:
When the extractable unit is closed and the
light is switched off, the control panel,
after 6 seconds, activates the stand-by
function, reducing the brightness of the leds.
This function can be stopped by pressing ON/
OFF or LIGHT key.
How the downdraft works
(+) KEY
This serves to bring the extraction panel up to a maximum height of 300mm and to automatically
set the first extraction speed when the panel reaches a height of 180mm. Pressing the button
again after 180mm is reached, will increase the extraction speed.
10
MODEL DD911
A: Light ON/OFF key
The light switches on and off only when the
carriage is fully OPEN.
Pressing this button with the carriage closed
will cause the carriage to open and then the
light will switch on .
The button also serves to switch off the light
if it is on.
B:
ON/OFF key
This starts the extraction carriage upward
movement and when it is fully open, it sets the
second extraction speed.
With the carriage open: it switches off the mo-
tor and if on, the light; then it retracts the ex-
traction carriage.
C:
(-) Key
This reduces the speed of the extractor motor
from the 4th speed until the motor switch-
es off, without closing the pull-out car-
riage.
D:
Indicators
•
This signals the speed setting, by only
the relevant LED switching on.(see
'Timing' on pg 11 for further information)
• This signals that all filters have been satu-
rated by all LEDs switching on.
E:
(+) Key
This increases the speed of the extractor mo-
tor, from 1st to 4th speed, without moving the
extractor panel.
F:
Timer
10 min after setting, it serves to stop the ex-
tractor motor, close the carriage and switch
the lights off, if they are on. The set function is
signalled by the flashing LEDs “D” for the set
speed. The timer can be cancelled by press-
ing the key again.
Other functions:
Automatic turn off:
After 4 hours of continuous working from
the last function selection, the appliance
turns off and closes automatically.
Grease filters saturation:
After 30 hours of working, the speed indica-
tors “D” will all flash simultaneously, signaling
the grease filters saturation.
To reset this alarm, hold down the “TIMER”
button for at least 3 seconds, while the car-
riage is open.
Calibration:
The cooker hood carries out its self
calibration every 3 complete cycles of its
extractable unit.
By pushing the “TIMER” key 6 times consec-
utively (MAX break between one push and the
other is 3 sec.) all the leds will flash and the
calibration will be reset.
After the next 3 cycles the downdraft will carry
out its self calibration.
Stand-by:
When the extractable unit is closed and the
light is switched off, the control panel,
after 6 seconds, activates the stand-by
function, reducing the brightness of the leds.
This function can be stopped by pressing ON/
OFF or LIGHT key.
How the downdraft works
TIMER
10 minutes after pressing this button and setting the function, it serves to stop the extractor motor
and close the carriage.
