Instruction manual DD606BK
14
Please keep this instruction manual for future reference
ELECTRICAL CONNECTION
WARNING:
Place the metal box containing the electronic components at a distance of no less than 65cm from
gas operated hobs or in any case, 65cm from the suctioning surface of the cooker hood.
NOTE:
We recommend installing the metal box containing the electronic components at least 10cm
above floor level and at a suitable distance from all heat sources (e.g. ovens or hobs).
CAUTION:
This appliance is fitted with an H05 VVF 3 conductor, 0.75mm
2
(neutral, phase, and ground)
power cord.
This can be connected up to a 220 - 240 V monophase electrical network through a CEI 60083
approved power socket, which must remain accessible after installation, in compliance with
installation regulations. We decline any responsibility in case of accidents caused by a lack
of ground connection or incorrect ground connection. The appliance must be fed through a
differential protection device (RCD), with a nominal residual current not exceeding 30mA. If the
power cord is damaged, call the Caple after-sales service to avoid any risk.
WARNING:
› The downdraft connection to the electrical network must be carried out only by professional
and qualified technicians.
› The downdraft must be connected to a properly installed and suitable electrical network.
› The electrical system must comply with VDE0100 standard.
DANGER:
If the cooker hood presents any anomaly, disconnect the appliance or remove the fuse
corresponding to the appliance power disconnecting line. If the appliance has no plug or if the
plug is not easily accessible, then a device needs to be fitted to cut it off from the electric network;
this device must have an opening distance between contacts on all poles of at least 3mm.
