Instruction manual FGC620 FGC720 FGC920
12
Please keep this instruction manual for future reference
After hanging the hood on the bracket, remove the grease filters, mark 2 holes inside the hood for
safety screws. After marking, remove the hood, drill two holes and insert 2 wall plugs and finally
fix the safety screws with 2 screws (ST4x30mm).
Fix the one-way-valve to the air outlet of the cooker hood. Then, attach the exhaust pipe onto the
one-way-valve as shown below.
6
Instruction manual FGC
Please keep this instruction manual for future reference
12
6
6
Fix the one-way-valve to the air outlet of the cooker hood. Then, attach the exhaust
pipe onto the one-way-valve as shown below.
Exhaust pipe
Cooker hood
After hanging the hood on the bracket , remove the Alu Filters , mark 2 holes
inside the hood for safety screws .After marking , remove the hood ,drill two
holes and insert 2 pcs of Wall Plugs and finally fix the safety screws with
2 screws ST4x30mm.
Exhaust Pipe
Cooker Hood
