• Remove the three screws in the blade assembly and
remove it.
• Replace the blade.
• Insert and tighten the three screws.
Adjusting the blade:
• Tighten the two blade adjusting screws equally to ensure
uniform wear and longer life.
Blade assembly
fixing screws
Adjusting screw
IMPORTANT
After replacing the blade, return the adjusting screws to
their original position (see photo) to prevent damage to
the blade.
