6. OPERATING INSTRUCTIONS
Position A Position B
6.1.1
Move the lever to position A to operate the feed roller.
6.1.2
Feed prunings and branches up to 25 cm in diameter into the feed
hopper. Accompany them in and let them drop.
6.1.3
Set the delivery mouthpiece in the safest position to prevent injury.
6.1.4
If the motor loses revs or power due to blockage, proceed as
follows:
- Stop feeding in material.
- Immediately move the feed roller lever to position B
(reverse).
1. Wait until the machine has freed itself of material and the motor
speed has increased to the correct number of revs.
6.1.5
What to do when you have finished the work:
2. - Check that there is no more material in the shredding chamber.
3. - Switch off the motor.
Disconnect the power takeoff and remove the cardan shaft (tractor
version).
