Caravaggi CIPPO 25 - 2. DIMENSIONS, WEIGHT & TRANSFERS POINTS

2. DIMENSIONS , WEIGHT & TRANSFERS POINTS
Diesel model Tractor model
LENGTH mm 4000 LENGTH mm 3900
WIDTH mm 1590 WIDTH mm 1250
HEIGHT mm 2400 HEIGHT mm 2400
WEIGHT Kg. 1345 WEIGHT Kg. 780
L
WA MAX
107 dB L
WA MAX
/
3
2
4
A
D
1
7
E
B
C
6
5
1 HOPPER 5 ROAD FRAME
2 EXHAUST FAN 6 TRACTOR P.T.O.
3 DIESEL ENGINE 7 3
rd
POINT FRAME
4 WHEELS
