19
SETUP AND CALIBRATION, Cont.
MODEL 210 Only
During the setup and calibration process it is necessary to enter operational parameters via the
210's keypad. Pressing the ENTER key without
entering a new value will retain the current
setting and advance the 210 to the next prompt. To change a setting, enter a new value and
press the
ENTER
key. This will save the new value and advance the 210 to the next prompt.
Pressing the
ASTERISK
key will "backup" to the previous prompt.
CAUTION: The membrane keypad is not to be operated with pointed objects
(pencils, pens, fingernails, etc). Damage to keypad resulting from this practice will
NOT be covered under warranty.
Enter Setup Mode
To enter the setup mode, with the indicator ON, insert a small screwdriver or other tool through the
calibration switch access hole on the rear panel. Press and release the calibration switch. The
menu SetUP will be displayed. Continue to press and release the switch to rotate through the
beginning point for entering the setup mode.
SEtUP Setup Mode (starts at USA prompt)
A-d
Analog to Digital Filtering (starts at dFLt= prompt)
CAL Calibration (starts at CAL1 prompt)
Sio Serial Input/Output (starts at BAUD prompt)
Print Print Tab Settings (starts at PORT prompt)
F SPAn Fine Span Adjustment
Hi rES Display high resolution weight mode
LoCoUt Key lock out function
dAC Digital to Analog Converter (If DAC board is installed, Calibration of 10 volt or
4 to 20 mA Analog Output)
If you press the
ENTER
key at the SetUP prompt, you may proceed through to the next section (up
to and including fSPAn ) by pressing the
ENTER
key.
NOTE! Setup may be interrupted at any time. ALL data previously entered and
finalized with the ENTER key will be retained in the non-volatile memory.
Pressing the calibration switch
at any prompt
will return you to the SEtUP menu. To exit setup,
press the
ASTERISK
key with any of the above menu selections displayed or cycle power at any
time (press the
ON/OFF
key twice).
NOTE!
With the exception of the SEtUP prompt, the prompts displayed for each
section are different if you push the calibration switch instead of pressing the
ENTER
key to proceed through the section.
For example
, if you press the calibration switch
with the SEtUP displayed, the next prompt displayed will be A-d. If you step through
the setup prompts by pressing the
ENTER
key, the next prompt displayed will be A-d?.
In additon, at a prompt with the ? displayed, you must press the
ENTER
key, the
1/YES
key then the
ENTER
key again to proceed with that section. To skip the
section and advance you to the next menu selection, press the
ENTER
key twice.
