43
PART IDENTIFICATION
(Front Enclosure Sub Assembly)
ITEM NO. QTY.
205
QTY.
210
PART NUMBER DESCRIPTION
1 14 14 6013-0039 NUT HEX #6-32
2 1 1 6013-0297 NUT 10-32 HEX
3 3 6021-0596 10-32 x 0.5 HHB SS
4 3 6021-0623 SCW PAN HEAD #6-32 x .750 PDMS
5 1 1 6024-0037 WASHER – LOCK #10 HEL SPLIT
6 10 10 6024-1078 WASHER FLAT #6 NEOPRENE BACKING S.S.
7 3 3 6024-1081 WASHER FLAT #10 NEOPRENE BACKING S.S.
8 1 1 6560-0064 DESSICCANT 1 x 1 BAG
9 1 1 6610-5002 GROUND LUG
10 3 3 6610-5007 CABLE CLIP
11 4 4 6680-0004 WASHER LOCK INT. TOOTH #6 Z/P
12
13 4 4 6680-1049 SPACER #6 x .375 NYLON
14 1 1 6710-1017 TAPE DBL SIDED 1.0 WIDE 45 MIL THK.
15 1 1 8200-B014-08 GASKET FOR 210 ENCLOSURE
16 1 1 8200-B020-08 COVER, BATTERY
17 1 1 8200-B021-08 GASKET: BATTERY DOOR
18 1 1 8200-C015-0A WELDMENT: BEZEL FOR 210
19 1 1 8200-C017-0A WELDMENT: ENCLOSURE, FRONT
20
21 1 8200-D100-08 KEYPAD: 205 DWI
22 1 8200-D201-0A PC BD, ASSY. 205 MAIN
23 1 8200-D201-1A PC BD, ASSY. 210 MAIN
24 1 8200-D202-08 KEYPAD: 210 DWI
To Next Page
