Cardinal 200 Series User Manual

44
PART IDENTIFICATION
(Final Assembly)
ITEM NO. QTY.
205
QTY.
210
PART NUMBER DESCRIPTION
1 1 1 593GR986 SERIAL TAG ASSEMBLY
2 11 11 6021-1142 SCW ROUND HEAD #10-32 x 0.625
3 1 1 6021-1143 SCW FILLISTER #10-32 x .625 S.S.
4 12 12 6024-1081 WASHER FLAT #10 NEOPRENE BACKING S.S.
5 1 1 6650-0087 LABEL: MADE IN THE USA
6 1 1 8200-D207-0A SUB ASSEMBLY: REAR ENCLOSURE
7 1 8200-D208-0A SUB ASSEMBLY: FRONT
8 1 8200-D208-1A SUB ASSEMBLY: FRONT 205
